August 2024 APR Rewards

bomber, CAD Diagrams, hi-rez, launch vehicles, Monthly Historical Documents Program, Patreon, rockets, space shuttle, spaceplane, stealth, transports, VTOL No Responses »

Sep 012024

The rewards went out this AM bright and early. They include:

Diagram: Two sheets of Rocketdyne schematics for the Space Shuttle Main Engine and propulsion system

Document: “B-1B New Strength for America’s Defense” An early 80’s brochure on the then-forthcoming B-1B

Document: “Aerojet propulsion for Space Systems,” a very nicely illustrated booklet on the AJ10-137, the main engine of the Apollo CSM

Document: Two articles in French on VTOL Aircraft from the ICARE revue De L’Aviation Francaise “Salon 69”

CAD Diagram: WIP of the Boeing Model 2000-201 VTOL stealth spec ops transport

If you are interested in helping to preserve this sort of aerospace history, consider signing up for the APR Monthly Historical Documents Program for as little as $1.50 per month:

https://www.aerospaceprojectsreview.com/monthly.htm

Douglas D-3203-29

hi-rez, jetliner, Monthly Historical Documents Program, Patreon, transports No Responses »

Jul 172024

A general arrangement diagram of the Douglas Model D-3203-29. This was a modified DC-9-50, appears to be the basic design for the MD-80, dated 7-26-1977.

The full-rez scan (more than ten times larger than this one) has been made available as a bonus to above-$10 subscribers and Patrons. If interested in such things, consider subscribing:

https://www.aerospaceprojectsreview.com/monthly.htm

Cyanotypes: closing up shop

bomber, Dyna Soar, hi-rez, hypersonic, jetliner, launch vehicles, nukes, Recon, research, rockets, space shuttle, spacecraft, spaceplane, stealth, transports, VTOL No Responses »

Jul 082024

I’ve shut down production of cyanotype blueprints for the time being. What I’ve got is what there is; I’ll leave the catalog page up while I still have a supply, but I’ll shut it down when I run low and sell the rest on ebay. Get ’em while ya can.

https://www.aerospaceprojectsreview.com/catalog/cyan.htm

June 2024 APR rewards

hi-rez, launch vehicles, Monthly Historical Documents Program, Patreon, rockets, spacecraft, spaceplane, stealth, transports No Responses »

Jul 012024

A day late, but I’ve sent out the June 2024 rewards to APR Patrons/Subscribers. Includes:

1: A pack of X-30 NASP propaganda. Seven double-sided 8X10 glossies, a double-sided poster, a bumper sticker and an emblem sticker.

2: “Non-Planing Seaplane Study” by Convair, 196. Two presentations; The $4 and up subscribers get not only the cleaned-up report, but the original as-scanned negative-image transparencies. marvel at the liberal use not of white-out but of black-out.

3: Detailed diagram of the KC-135 (1/40 scale model)

4: In lieu of a CAD diagram, first public art of the F-117A, 1988

If you are interested in helping to preserve this sort of aerospace history, consider signing up for the APR Monthly Historical Documents Program for as little as $1.50 per month:

https://www.aerospaceprojectsreview.com/monthly.htm

Tanker concept art

hi-rez, Monthly Historical Documents Program, Patreon, transports No Responses »

May 212024

Procured from ebay, this piece of concept art sadly comes without context. It shows a tanker aircraft (pretty much a McDonnell-Douglas YC-15, though the engines appear a bit different… perhaps higher bypass turbofans) topping up an F-15.

The full-rez scan of the art has been made available as a thank-you to APR Patreon and Historical Documents Program patrons at the $4 and above level, placed in the 2024-05 APR Extras Dropbox folder. If interested in this or if you are interested in helping to fund the preservation of aerospace history, please consider becoming a patron, either through the APR Patreon or the Monthly Historical Document Program.

Dual-fuselage DC-9

jetliner, transports No Responses »

Feb 182024

NASA artwork (probably 1970s/early 80’s) of a dual-fuselage DC-9. This would double the capacity while not doubling the weight; drag would go up, but so would aerodynamic efficiency due to increased effective aspect ratio of the wing, as well as being more structurally sound for the weight. The need for a pretty wide runway is something of a concept-killer, though.

Vulcan “Starfire”

transports, VTOL No Responses »

Oct 102023

Sadly not a lot of info on this. The Vulcan Aircraft (Houston, TX) “Starfire” concept from the mid/late 1980s used lift vans and vectored thrust for VTOL. Both military and civilian uses planned. Seems kinda reasonable, if perhaps a bit light on power, The basic design seems like it might be more practical today, though of course someone would try to make it all-electric.

August 2023 Rewards

bomber, CAD Diagrams, hi-rez, jetliner, launch vehicles, Monthly Historical Documents Program, Patreon, rockets, space shuttle, space station, spacecraft, spaceplane, stealth, transports 1 Response »

Sep 012023

The rewards for August, 2023, have been released. They include:

Document: Report No. ZD-013, “Preliminary Detail Specification for United States Navy Class VP Long Range Patrol Seaplane,” Convair, 1 April 1946

Document: “Space Shuttle: What Will It Do?” A 1970’s brochure describing the Shuttle, with six full-color full page illustrations

Art: McDonnell-Douglas lithograph of “NASA Earth Orbital Space Station”

CAD Diagram: Northrop Grumman Next Generation Long Range Strike

If you would like to help fund the acquisition and preservation of such things, along with getting high quality scans for yourself, please consider signing on either for the APR Patreon or the APR Monthly Historical Documents Program. Back issues are available for purchase by patrons and subscribers.

And as happens far too often, I’ve been remiss in my PR campaign. The rewards for July, released a month ago, included:

Document: “C-5 Galaxy Pocket Guide,” brochure giving info on the C-5

Document: GDIC-64 O29-21, “Alighting Gear Convair Model 48 Light Armed Reconnaissance Airplane,” an illustrated report on the landing gear for Convairs competitor for the OV-10

Document: “Police Department Lecture #3 Effects of Atomic Weapons,” an early-50’s paper describing what NYC could expect int he event of a nuclear strike

Diagram: EMW “Wasserfall,” German WWII surface to air guided missile

CAD Diagram: Boeing 2707-100-derived bomber

Recent acquisitions

bomber, hi-rez, hypersonic, jetliner, launch vehicles, Monthly Historical Documents Program, Patreon, Patreon catalog, research, rockets, space station, spacecraft, spaceplane, transports 2 Responses »

Aug 182023

Thanks to ebay and my fabulously lean bank account, I have recently procured a number of items of potential interest:

“NASA Earth Orbital Space Station,” a poster-sized lithograph from McDonnell Douglas depicting a space station that tumbles for artificial-G.

“Re-Entry Payload Launch Vehicle,” A *brief* General Dynamics presentation on a vehicle to launch re-entry vehicles such as MIRV warhead shapes

“Proposed Development Program on Rocket-Type Missiles,” a 1948 Convair report on early ballistic/boost glide missile concepts, that would lead to Atlas. Includes some fantastic large format layout diagrams.

“Detail Specification for Consolidated Vultee Model 117 Airplane Class VR Transport Flying Boat,” August 1950, all the details on the then-brand new Tradewind.

“Detail Specification for Class VP Long Range Patrol Seaplane,” Consolidated Vultee 1946, all the details on a proposed flying boat patrol/bomber

32 issues of “Astronautics” magazine from 1957 to 1969, mostly 57-59 and 63 or so.

The lithograph and the reports will be scanned and put forward for consideration for monthly rewards; the magazines will have the interesting bits scanned and made available to the subscribers/patrons.

New PBYs?

future projects, transports No Responses »

Jul 252023

Color me not just skeptical, but damn near dismissive:

Reviving The PBY Catalina For Modern Warfare Is This Company’s Goal

I fully support the manufacture of newly designed, modernized PBY “Catalina” flying boats. Damned things were awesome 80 years ago; had I buckets of money, I’d fund the program myself. But *this* program does not inspire a great deal of (i.e “any”) confidence. All they show are a few *very* low re and simplistic CG renders of a modernized PBY… lacking the braces that kept the parasol wing from snapping off during maneuvers. I know materials have advanced a lot since the 1930’s, but come *on,* that design just don’t look right without those braces.

Recall that just over a year ago an Australian company said they were going to remanufacture the Grumman Albatross flying boat. The last “news” update to their website was December of 2022.
