3D Printer “Crowdfund”

American Nuclear Explosive Devices, Dyna Soar, fighter, future projects, hi-rez, launch vehicles, nukes, research, rockets, space shuttle, spacecraft, spaceplane, US Bomber Projects, US Fighter Projects, US Launcher Projects, US Recon & Research Projects, US Spacecraft Projects 3 Responses »

May 232024

So after having the 3D printer for a while and running a *lot* of resin through it, I have achieved some good things. I’ve learned enough to know that there are some things that I plan on producing as full 3D-printed kits, some to be converted into metal castings. I have a few product lines that I want to do:

1: 1/285 (wargaming scale) “minis” of a range of appropriately sized unusual, rare, interesting and projected aircraft/spacecraft

2: “Mini”-sized, but of various scale, aircraft and spacecraft to go with each issue of US Aerospace Projects

3: 1/18 scale models of each American nuclear bomb/warhead/re-entry vehicle. This will range from the downright dinky to the “I’m not sure how to squeeze this out of the printer,” like the Mk 17 and the Flashback. I’ve successfully printed prototypes of the Fat Man and Little Boy A-bombs in 1/18, but they need to be revised.

4: Just whatever strikes my fancy by way of interesting aerospace/sci-fi concepts.

The eventual 3D printed kits will be pricier than if they were cast resin “garage” kits, but this will allow me to make them on demand. I hope there is interest in this sort of thing. To that end, and to help refill my depleted coffers, I’m making available a “crowdfunding” project with three levels. What you will receive are the actual 3D printed components. Each level builds on the prior… Level 2 gets you the Level 1 stuff, Level 3 gets you 1 and 2. No additional postage is required for continental US address… Hawaii, Alaska, Canada, the rest of the world, contact me and I’ll work out the additional postage cost.

Note: many of these are “prototype” kits, with revisions and improvements possible or even probable. And some of these are not planned to be released further. This will be your only chance to get them, at least in this format.

Level 1. You will receive:

1/285 X-20 Dyna Soar spaceplane
1/285 XF-103 Mach 3 interceptor
1/285 Project Pluto nuclear ramjet
1/285 X-15 set (X-15, X-15A2, X-15A3, X-15/SERJ)
1/18 Davy Crockett battlefield atomic warhead w/stand

Crowdfund level 1: $60 in the continental US:

——–

Level 2. You will receive:

1/18 US Atomic Artillery Shells w/stand
1/144 X-20 Dyna Soar
1/18 M61 Vulcan Gatling Gun w/stand
1/18 Mk 72 Nuclear Warhead/Re-Entry Vehicle

Crowdfund level 2: $100 in the continental US:

——–

Level 3. This part will not ship immediately, as some of it remains unfinished. You will receive:

1/285 XF-103 w/missiles
1/350 Orion Nuclear Pulse Vehicle (with stand… not yet finalized)
1/2000 Aldebaran Concept Vehicle
Cast Metal 1/285 X-20 + XF-103 + X-15 + Pluto: Depending on the success of the casting process. Not all are guaranteed.

Crowdfund level 3: $200 in the continental US:

——–

Aug 212020

Forthcoming

spacecraft, US Spacecraft Projects No Responses »

Feb 102019

A *very* early look at issue 6 of US Spacecraft Projects:

Manned Mars Spacecraft

nukes, Patreon, rockets, spacecraft, US Spacecraft Projects No Responses »

Nov 022018

This is what a manned mission to Mars dating from the late Apollo era would have looked like: a cluster of hydrogen tanks with a small number of NERVA nuclear rockets. The spacecraft would have been relatively gigantic as it leaves Earth orbit; large enough that it would have been assembled in space from at least six Saturn V launches. When it returns to Earth it would have been little more than the mission module; this would blast past Earth and continue in solar orbit while the astronauts and a few trifling hundreds of pounds of Martian souvenirs would have plowed into Earths atmosphere in a compact entry capsule. The mission module itself is described fully and heavily illustrated in US Spacecraft Projects #3.

I’ve uploaded the full rez versions of these renderings to the 2018-11 APR Extras folder on Dropbox, available to all APR Patrons at the $4 level and above. If this sort of thing is of interest, please consider signing up for the APR Patreon.

NEW: US Bomber Projects #21 and Spacecraft Projects #05

bomber, future projects, nukes, rockets, space shuttle, space station, spacecraft, spaceplane, US Bomber Projects, US Spacecraft Projects 2 Responses »

Apr 262018

US Bomber Projects #21 and Spacecraft Projects #05 are now available.

US Bomber Projects #21

Cover art was provided by Rob Parthoens, www.baroba.be

US Bomber Projects #21 is now available (see HERE for the entire series). Issue #21 includes:

Convair Submersible Nuclear Ramjet: a Mach 4 manned nuclear powered flying submarine
Bell MX-776: an early post-war pilotless airplane
Convair Manned Flyback Atlas: an unconventional recoverable ICBM
DTNSRDC PAR-WIG Strategic Deterrent: a low-flying aircraft packing 4 Trident ballistic missiles
Boeing Model 464-197: a supersonic B-52
Martin Model 151-K: a pre-war twin-engined medium bomber
Boeing Cruise Ballistic Missile: an entire aircraft packed into a silo, carrying an ICBM
MC-747 Air Mobile System: a 1973 concept for carrying up to seven ICBMs in a modified cargo jet

USBP #21 can be downloaded as a PDF file for only $4.25:

——–

US Spacecraft Projects #5

US Spacecraft Projects #05 is now available (see HERE for the entire series). Issue #05 includes:

Project HORIZON Lunar Lander: a late 1950’s US Army concept for a manned Lunar lander
Lockheed-Martin Mars Ascent/Descent Vehicle: A very recent concept for a future manned Mars vehicle
JPL Interstellar Precursor: a 970’s design for a space probe to interstellar space
Lockheed Modular Rotating Space Station: a truly gigantic design circa 1970
Lockheed Payload Carrier: an early 1960’s spaceplane for space station logistics
Martin-Marietta Winged NIMF: a nuclear powered “hopper”
Lockheed CL-414: a capsule for Man in Space Soonest
NASA HAVOC: High Altitude Venus Operational Concept, a 2015 project for manned exploration of the atmosphere of Venus

USSP #05 can be downloaded as a PDF file for only $5.25:

——–

The previous releases of US Aerospace Projects:

US VTOL Projects #2

SOS Interceptor: A US Navy Mach 3 aircraft with jettisonable wings
Lockheed GL-224-3: A small battlefield surveillance and ground attack plane
Phalanx Dragon MP-18: An unconventional small civilian transport
Lockheed L-161-1: An early concept for a variable geometry roadable helicopter
GE Supersonic V/STOL: A supersonic strike fighter with flip-out lift fans
Convair ANP-VTOL: A nuclear-powered ground-effect craft of the Navy of unusual configuration
Piasecki 16H-3: A compound helicopter for high speed passenger transport
Boeing Vertol Model 147: A tilt-wing close support fire support design for the US Army

USVP #2 can be downloaded as a PDF file for only $4.25:

——–

US Research & Recon Projects #2

Lockheed A-1: The first true design leading to the SR-71
Bell MX-2147 Model 105: The high altitude “X-16”
Boeing/CRC/AMROC X-34 Reference Configuration: A reusable launcher test vehicle
Martin Model 159: A scout/observation float plane
NASA-Langley Low-Boom Demonstrator: a recent design to demonstrate quiet SST tech
McDonnell-Douglas DC-9 Super 80 Propfan Configuration 1: A fuel efficient transport demo
Convair “HAZEL” MC-10: An inflatable Mach 3 plane for the Navy
Republic Manned Hypersonic Reconnaissance Vehicle: an early scramjet concept

USRP #2 can be downloaded as a PDF file for only $4.25:

——–

Thousand Astronomical Unit spacecraft

nukes, rockets, spacecraft, US Spacecraft Projects 3 Responses »

Aug 102016

Starting in the 1970s and running through much of the 1980’s, the Jet Propulsion Laboratory ran numerous studies of Thousand Astronomical Unit (TAU) spacecraft. These were somewhat akin to Voyager class probes, but with important differences. instead of small RTGs for power, they would use SP-100 class fission reactors, mounted many dozens of meters away at the end of long booms. Located at the center of mass of the system would be a bank of ion engines; the nuclear electric propulsion system would operate for *years* to boost these craft to extremely high speeds. Still, it would take decades for them to travel 1,000 AU from the Sun, many times further than Pluto. There, large optical telescopes would take parallax measurements on distant stars; by positioning numerous TAU craft in every direction, the measurement baseline would be vast, and precise distance fixes could be made for stars on the other side of the galaxy.

A number of TAU designs were examined, but the one shown here in JPL art seems to be pretty representative. These probes would have to be engineered with a high degree of both reliability and autonomy as their main observation missions would only begin something like 50 years after launch. Diagrams of a different design and more information were presented in US Spacecraft Projects #3.

General Dynamics VL-3A

hypersonic, rockets, space shuttle, space station, spacecraft, spaceplane, transports, US Spacecraft Projects No Responses »

Jun 222016

A General Dynamics concept for a logistics spacecraft (personnel and cargo transfer to/from space stations) from 1966. The VL-3A was a narrow lifting body design to be launched by a Titan IIIc, and featured flip-out wings and turbojets for runway landings. The VL-3A and other spaceplanes were presented in US Spacecraft Projects #2.

Graphics Design and USBP

bomber, US Bomber Projects, US Fighter Projects, US Launcher Projects, US Spacecraft Projects, US Transport Projects, US VTOL Projects 2 Responses »

May 012016

I admit that the USBP series looks kinda… bland. It’s text and line drawings; not a whole lot can be done to jazz that up. Especially since I have no head for graphics design whatsoever apart from layout diagrams.

Still, one reader sent me a mockup of a revised cover of USBP #18:

Things are moved around a little bit, but the obvious change is the addition of color. The suggestion was also made to consider color-coding each title in the USXP series. Just off the top of my head, I came up with:

Bombers: Olive Drab

Spacecraft: Black

Launch Vehicles: Blue on bottom, transitioning to black at the top

Fighters: slightly bluish gray (like the F-15 or F-22)

Transports: ??

VTOL: ??

The USBP#18 cover was re-done to reflect this, thusly:

Thoughts? Is this more appealing?How about color-coding… good idea or not? And if so, what colors?

I tried something vaguely like this once before, with USBP#05.

US Spacecraft Projects #4, Transport Projects #5 now available

jetliner, rockets, spacecraft, spaceplane, transports, US Spacecraft Projects, US Transport Projects No Responses »

Jan 232016

USSP #04

US Spacecraft Projects #04, the Lander Special is now available (see HERE for the entire series). Issue #04 includes:

GE Electrically Propelled Cargo Vehicle: A lunar lander with a nuclear reactor and ion engines to reduce the cost of lunar logistics
Douglas LASS: Landing an S-IVb stage on the moon
Convair PLAME: VTOL crew return with jet engines
North American Mars Excursion Module: the iconic conical Mars lander
Martin-Marietta Ballistic NIMF: A nuclear “hopper”
Early LEM: One of the first recognizable designs, by Maxime Faget
ROMBUS: probably the largest lunar lander seriously proposed
Boeing Lander Module 2: A recent Mars crew lander

USSP #04 can be downloaded as a PDF file for only $5.25:

——–

—–

USTP #05

US Transport Projects #05 is now available (see HERE for the entire series). Issue #05 includes:

Boeing Model 820-100: The B-52 can haul more than bombs…
Lockheed Nuclear Tug: Want to tow two C-5s across an ocean?
Martin Super Ocean Transport: A WWII-era design for a post-war giant passenger transport
HOT EAGLE: 13 Marines to Benghazi in minutes
Sikorsky SST: An early supersonic transport concept
Lifting Body Cargo Airplane: A wartime design for a multibody design with a separate cargo module
Resource Air Carrier: A giant “flying pipeline” to haul petroleum
Boeing Model 763-165: A side-by-side New Large Airplane design

USTP #05 can be downloaded as a PDF file for only $4.25:

——–

—–

AND don’t forget these…

—

USLP 03

Issue 03 of US Launch Vehicle Projects includes:

Juno V/Titan/Nomad: A 1958 concept for a space launcher using an ICBM for upper stages
Convair ATE Nova: A 1963 idea for winged airbreathing boosters
B-70/Gemini: Using a bomber as a booster
Phase II VTOHL Orbit-On-Demand: a 1985 concept for a relatively small two stage to orbit spaceplane
NASA Lewis Saturn Ib/Centaur/Kick Stage: a high energy upper stage
NASA MSC 042B/Titan IIIL6: a straight-winged orbiter atop a large Titan derivative
Heavy Lift Titan: A large diameter Titan core with three Shuttle boosters
Escher “Unshackled”: An unconventional idea for a lunar rocket

USLP #03 can be downloaded as a PDF file for only $4.25:

——–

—–

Large format USBP drawings, Issues 10-12

The CAD drawings created for USBP reformatted and rescaled for 11X17 collected in a separate volume. Drawings have in some cases been corrected, improved and added to.

USBP 11X17 10-12 collects the diagrams created for issues 10, 11 and 12, including:

Boeing Model 464-34-3, Republic mach 7, Lockheed CL-1301-1, Convair WS-125A, Boeing 484-415, Martin Model 223-10, Boeing Model 814-1010 Dyna Soar, Martin Model 192-5, Boeing Model 464-40, Boeing Model 701-218, Northrop Nuclear flying wing, North American D118, Martin Model 223-11, North American Model 705-00-04, Bell/Martin 464L, Boeing B-1, Boeing Big Bird BB 6800, Boeing Model464-41, Douglas MX-2091-E, Boeing Model 701-238, Martin Model 223-12, Northrop Nuclear Flying Wing, Rockwell MRCC, Lockheed CL-820-8

USBP11x17-10-12 can be downloaded as a PDF file for only $11:
————–

—-

Large format USBP drawings, Issues 13-15

The CAD drawings created for USBP reformatted and rescaled for 11X17 collected in a separate volume. Drawings have in some cases been corrected, improved and added to.

USBP 11X17 13-15 collects the diagrams created for issues 10, 11 and 12, including:

Ryan Model 162, Boeing Orbital bomb, Northrop Atomic Wing, Consolidated Vultee High Speed Flying Boat, Martin Model 189, Boeing Model 464-046, Curtis F-87C, Boeing Model 701-247, Lockheed WS 464L Dyna Soar, McDonnell WS 464L Dyna Soar, North American WS 464L Dyna Soar, Republic WS 464L Dyna Soar, Convair WS 464L Dyna Soar I, Convair WS 464L Dyna Soar II, Douglas WS 464L Dyna Soar, Northrop N206 WS 464L Dyna Soar, Boeing Model 814-1010 Dyna Soar II, Bell/Martin WS 464L Dyna Soar, Boeing Model 2050E Dyan Soar, Boeing Dyna Soar/ Titan IIIc, Bell D2001 TS-149, Lockheed Harvey; Convair Model 35, Rockwell D661-27, Boeing Model 464-49, Boeing Model 988-123, Boeing Manned Orbital Bomber, Boeing Model 701-251

USBP11x17-13-15 can be downloaded as a PDF file for only $11:
————–

—-

The birth of aerospace mythology

US Spacecraft Projects 6 Responses »

Dec 212015

OK, so I wrote about the “Have Sting” orbital railgun, and produced some provisional diagrams of it, publishing them in US Space Projects #3. A blog article was written for War Is Boring discussing “Have Sting,” based in no small part on my diagrams. OK, so far so good. But then other blogs start writing about Have Sting, and an error is introduced.

Whenever a blog post links to my blog, a “pingback notification” is sent to my blog dashboard. I’ve just glanced at these, haven’t given them much thought. For the most part they seem to be just parroting the verbiage from the War is Boring piece. But with one change: “Have Sting” has become “Have Sling.” A “T” became an “L.”

Examples:
http://www.extremetech.com/extreme/219718-exploring-the-death-star-space-gun-america-never-built

In September, the Aerospace Project Reviews Blog published some fascinating diagrams depicting “Have Sling,” which aerospace historian Scott Lowther described as “[a] General Electric design for a gigantic orbital railgun.” Have Sling was never built, of course.

http://www.usaspeaks.com/news/exploring-the-death-star-space-gun-america-never-built/

September, the Aerospace Project Reviews Blog published some fascinating diagrams depicting “Have Sling,” which aerospace historian Scott Lowther described as “[a] General …

http://www.usaspeaks.com/news/exploring-the-death-star-space-gun-america-never-built/

http://www.viralnewstrend.com/exploring-the-death-star-space-gun-america-never-built/

And a bunch more, all seemingly the same post over and over.

And if you Google “have sling” and some other terms, some seriously wacky stuff appears, which I’m guessing is the result of some weird auto-translation:

http://www.bbtechnonews.com/index.php/2015/12/19/exploring-the-death-star-space-gun-america-never-built/

In September, the Aerospace Task Reviews Blog site released some remarkable layouts portraying “Have Sling,” which aerospace chronicler Scott Lowther

“Aerospace Task Reviews?”

And:

http://journalfocus.com/2015/12/exploring-the-death-star-space-gun-america-never-built/

Exploring the ‘Fatality Celebrity’ space gun America never built

UNITED STATE protection coordinators did at one time think about constructing a huge Fatality Star-like gun in space as component of the “Celebrity Wars” rocket protection program, as Warisboring’s Steve Weintz advised us this week in the middle of the hullaballoo of the position of The Pressure Awakens.

In September, the Aerospace Job Reviews Blog site released some interesting representations portraying “Have Sling,” which aerospace chronicler Scott Lowther…

… the styles explain a space tool the dimension of the International Space Terminal, each Lowther.

Buh?

So now when people try to research orbital railguns, there’s every chance that they will be presented with the fallacious designation “Have Sling.”

I just did a Google search on “railgun” and “have sling.” It spat back 741 results. “Railgun and “Have Sting” only produced 321 results. The lie traveled around the world while the truth was still putting on its boots.
