Radial-arm artificial-gravity space station concept art

 hi-rez, space station, spacecraft, spaceplane  No Responses »
May 282018


A piece of 1960’s aerospace concept art depicting a sizable (50 to 100 crew) space station equipped with three modules at the ends of arms, intended for artificial gravity via centrifugal force. Presumably the conical structural at the left would contain the nuclear reactor, shielding and radiations; presumably the modules on the hub at the far left would be non-rotating to aid spacecraft docking. Unclear what the source is… but I’d bet on either North American Aviation or Lockheed.

I have uploaded righ-rez scans of both sides of this B&W photo glossy to the 2018-05 APR Extras folder on Dropbox for APR Patrons at the $4 level and up. If you are interested in these  images and a great many other “extras” and monthly aerospace history rewards, please sign up for the APR Patreon. What else are you going to spend $4 a month on?

patreon-200

 Posted by at 11:28 am

Reusable Atlas model photos

 hi-rez, launch vehicles, Patreon, rockets, space shuttle, spaceplane  No Responses »
May 182018


In the 1960’s, prior to the Space Shuttle program, General Dynamics/Convair  studied using the Atlas ICBM as a space launch system. no surprise there. But one concept called for a nearly fully reusable Atlas, equipped with wings, jet engines, landing gear and a cockpit to recover the booster in one reusable piece. It would be topped with either an expendable Centaur and satellite/space probe upper stage or a smallish manned lifting body spaceplane with its own built-in  propulsive capability. At the time General Dynamics released sizable “educational” cards with information and photos of models of the reusable Atlas. Unlike the normal Atlas, this version did not drop the outboard “booster’ engines, but kept them throughout the mission. An inflatable, deployable afterbody was proposed to fair over the engines after burnout to reduce base drag.

I have uploaded righ-rez scans of both sides of this poster-sized card to the 2018-05 APR Extras folder on Dropbox for APR Patrons at the $4 level and up.

Additionally, a report on this concept is available as Space Doc 52.

If you are interested in these Reusable Atlas model images and a great many other “extras” and monthly aerospace history rewards, please sign up for the APR Patreon. What else are you going to spend $4 a month on?

patreon-200

 Posted by at 11:14 pm

Convair VL-3A model photos

 hi-rez, hypersonic, launch vehicles, rockets, space shuttle, space station, spacecraft, spaceplane  No Responses »
May 102018


The Convair VL-3A was a 1966 concept for a space station logistics spacecraft. It was a sleek, flat-bottomed lifting body featuring a twin tail and flip-out wings that would deploy shortly before landing to reduce the landing speed. It would be fitted with flip-out turbofan engines for range extension, self-ferry and control during landing. General Dynamics released sizable “educational” cards with information and photos of models of the spaceplane showing  how the wings would deploy from within the lower fuselage.

I have uploaded righ-rez scans of both sides of this poster-sized card to the 2018-05 APR Extras  folder on Dropbox for APR Patrons at the $4 level and up.

I also wrote about and illustrated the VL-3A in US Spacecraft Projects #2, showing the general arrangement of the design along with the disposable propulsion stage and the launch configuration atop the Titan III.

USSP #02 can be downloaded as a PDF file for only $6:



If you are interested in thes VL-3A model images and a great many other “extras” and monthly aerospace history rewards, please sign up for the APR Patreon. What else are you going to spend $4 a month on?

patreon-200

 Posted by at 1:04 am
