In the long, long ago, Lockheed tried to sell the F-22 to the US Navy. In order to accommodate the needs of Naval aviation, the aircraft would have had to have been massively modified… most obviously by giving the aircraft variable geometry wings like the F-14’s. Clearly the Navy didn’t go for it: the cost of the program would have been immense, as would have been the risks. The F-22 ended up being troubled enough with materials and maintenance nightmares; add to that the rigors of slamming into carrier decks, constant humidity and salt air, all the other bothersome details of operating from ships at sea; and add to THAT the fact that while the NATF (Naval Advanced Tactical Fighter)*looked* like the F-22, it would have shared very few structures in common with its Air Force cousin and would have been basically a new aircraft… it would undoubtedly have been massively expensive to a degree that even the F-35 would have been hard pressed to match.
